Key Features of the 3300 Vector VFD

⚙️ High-Performance Vector Control

The IDEEI 3300 vector VFD provides vector control for industrial applications that require controlled motor speed and torque. Detailed motor-control performance parameters are not specified in the available product data.

🔧 Multiple Power Ratings

The 3300 series includes the following actual models and power ratings:

3300-0R7G-4 –
0.75 kW
3300-1R5G-4 –
1.5 kW
3300-2R2G-4 –
2.2 kW
3300-004G-4 –
4 kW
3300-5R5G-4 –
5.5 kW
3300-7R5G-4 –
7.5 kW
3300-011G-4 –
11 kW
3300-015G-4 –
15 kW
3300-018G-4 –
18.5 kW
3300-022G-4 –
22 kW

📡 Position, Speed and Torque Control

The 3300 series supports integrated position, speed and torque control functions for industrial equipment requiring coordinated motor operation.

🔄 Multiple Encoder Options

Multiple encoder options are supported for feedback-based motor control. Compatible encoder models, wiring details and feedback specifications are not specified in the available product data.

🔌 Common DC Bus Support

The 3300 vector VFD supports a common DC bus according to the supplied product information. Detailed DC bus voltage and connection requirements are not specified.

🛑 Built-In Brake Unit

The supplied product information identifies a built-in brake unit for selected models from 0.4 kW to 37 kW. Availability for each listed 3300 model should be confirmed before ordering.

📶 RS485 Communication

The IDEEI 3300 series includes an RS485 communication standard for integration with compatible industrial control systems. The supported communication protocol and parameter settings are not specified.

Technical Specifications – 3300 Series Model Range

3300G-4 Series – Three-Phase 380-440 V

Input voltage: Three-phase 380-440 V | Control: Vector control | Communication: RS485

General Specifications

Ideal Applications

• Metalworking machinery requiring adjustable motor speed
• Drilling and cutting equipment requiring vector control
• Industrial machines requiring controlled motor torque
• Equipment using encoder feedback for position or speed control
• Industrial drive systems requiring RS485 communication

The supplied product image shows the IDEEI 3300 vector VFD used with metalworking equipment. Exact application suitability should be confirmed against the motor nameplate, load characteristics and machine requirements.

Frequently Asked Questions

What is the IDEEI 3300 vector VFD used for?

The IDEEI 3300 vector VFD is a general purpose inverter for industrial machines requiring vector control, adjustable speed, torque control or position control.

What power ratings are available for the 3300 series?

The available models are 0.75 kW, 1.5 kW, 2.2 kW, 4 kW, 5.5 kW, 7.5 kW, 11 kW, 15 kW, 18.5 kW and 22 kW.

Does this 3300 vector VFD support encoder feedback?

Yes. The 3300 series supports multiple encoder options. Compatible encoder models and detailed wiring requirements should be confirmed for the selected model.

Does the 3300 series support position, speed and torque control?

Yes. The 3300 series supports integrated position, speed and torque control functions according to the supplied product information.

What communication interface does this inverter use?

The IDEEI 3300 series uses an RS485 communication standard. The supported protocol and communication parameter settings are not specified in the available product information.

How do I select the correct 3300 model?

Select the model according to the motor power, input voltage, load type and required control functions. For model selection based on the motor nameplate, contact the IDEEI engineering team.
